Bose 802 III Series User Manual

2
SPECIFICATIONS
WARRANTY: 5 year limited warranty
External dimensions:
Single speaker: 13.5" H x 20.5" W x 13.0" D (34.3 x 52.1 x 33.0)cm
Packed system: 14.4" H x 21.8" W x 18.3" D (36.6 x 55.4 x 46.4)cm
Weight:
Single speaker: 29.3 lbs (13.29 kg)
Packed system: 32 lbs (14.5 kg)
Transducer:
Eight 4.5" environmental drivers per enclosure
Internal cabinet volume:
3,020.7 cu. In. (49.5 liters)
Port:
Type: Two round ports located central to each four speaker pattern.
Total port area: 6.0 sq. in. (38.9 sq. cm)
Port length: 7.5" (19.0 cm)
Resonance frequency: 50 Hz
Impedance:
8 ± 2 Ohm
Power handling:
240W continuous per IEC-268-5
Sensitivity:
91 dB SPL, 1W, 1m
Contents
Specifications ....................................................................................................................................2
Disassembly/Assembly Procedures ........................................................................................... 3-4
Figure 1. Schematic Diagram ..............................................................................................................4
Figure 2. Wiring Diagram ..................................................................................................................... 4
Figure 3. Driver Location Diagram.......................................................................................................4
Test Procedures ................................................................................................................................5
Main Part List.....................................................................................................................................6
Figure 4. Exploded View ......................................................................................................................6
Shading Network Part List ...............................................................................................................7
Figure 5. Shading Network Layout ......................................................................................................7
Packaging Part List ...........................................................................................................................7
Figure 6. Packaging View ....................................................................................................................7
PROPRIETARY INFORMATION
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION
OF BOSE
®
CORPORATION WHICH IS BEING FURNISHED
ONLY FOR THE PURPOSE OF SERVICING THE IDENTIFIED
BOSE PRODUCT BY AN AUTHORIZED BOSE SERVICE
CENTER OR OWNER OF THE BOSE PRODUCT, AND SHALL
NOT BE REPRODUCED OR USED FOR ANY OTHER PUR-
POSE.

Bose 802 III Series Specifications

General

Brand	Bose
Model	802 III Series
Category	Speakers
Language	English
