CROSSOVER PCB PARTS LIST
Miscellaneous
Reference
Designator
Description Material Number Note
- CAP, FILM, 125, 250V, 5%, 15uF 863360-156J2E
- CAP, FILM, 125, 250V, 5%, 5uF 863360-505J2E
- INDUCTOR, CUSTOM, 1mA, DCR0.22, 5%, 1.5mH 863381-1R5J
- INDUCTOR, CUSTOM, 1mA, DCR0.45, 5%, 0.8mH 863385-R80J
- TERMINAL, 250#0.8T, TIN PLATED, IN+ 862850-0010
- TERMINAL, 205#0.8T, TIN PLATED, IN- 862852-0010
- CABLE TIE, PA66, 160X2.5mm 862857-0010
- SUPPORT, SPACER, SS4-6, PA66 862859-0010
- SOLDER, WIRE, D9930C, Sn/0.7Cu, D1.2mm 862860-0010
- ADHESIVE, HIGH BONDING, SA-6060P 863031-0010
- ADHESIVE, SILICONE RTV, KE-45 863034-0010
- CABLE ASSY, CROSSOVER, HF 863541-0010
- CABLE ASSY, CROSSOVER, LF 863545-0010
IO ASSY PARTS LIST
Miscellaneous
Reference
Designator
Description Material Number Note
-
PLATE, CONN MTG, I/O 843682-0110
-
GASKET, I/O PANEL 843982-0110
-
GASKET, CONNECTOR, I/O 843986-0110
-
SOLDER, WIRE, D9930C, Sn/0.7Cu, D1.2mm
862860-0010
-
CONN, NL4, 4P, R, ST, TH, 31X26mm, 2NUTS 862939-0010

Bose AMM108 Specifications

General

Brand	Bose
Model	AMM108
Category	Speakers
Language	English
