Installers Guide to the Bose® Serial interface June 28, 2011
Bose Confidential Information Page 37/42 Do Not Redistribute
7 Appendix
7.1 Source Enumerators
These are the values returned by the SR command (see Section 6.8 SR -Query Zone Source.)
Table 7-1 Source Enumerators
Source Name
Value)
Explanation
OFF
0x00
Zone is OFF
Reserved
0x01
Reserved
0x02
Reserved
0x03
INPUT_ID_FM
0x04
FM band of tuner
INPUT_ID_AM
0x05
AM band of tuner
Reserved
0x06
Reserved
0x07
Reserved
0x08
INPUT_ID_IN1_HDMI
0x09
Rear HDMI input connector nearest TV
INPUT_ID_IN2_HDMI
0x0A
Rear HDMI input connector
INPUT_ID_IN3_HDMI
0x0B
Rear HDMI input connector
INPUT_ID_IN4
0x0C
Rear Analog, Coax, or Optical input connector
INPUT_ID_IN5
0x0D
Rear Analog, Coax, or Optical input connector
INPUT_ID_TV
0x0E
TV optical audio input connector
INPUT_ID_USB0
0x0F
Front USB connector
*
INPUT_ID_IPOD
0x10
iPod connector
INPUT_ID_INSTALLIQ
0x11
Unify menus
INPUT_ID_BOSELINK_1
0x12
Bose® link stream 1 input
*
INPUT_ID_BOSELINK_2
0x13
Bose® link stream 2 input
*
Reserved
0x14
INPUT_ID_HDMI_FRONT
0x15
Front HDMI input connector
*
INPUT_ID_AV_FRONT
0x16
Front Analog input connector
*
INPUT_ID_PTS
0x17
System Information Screen
7.1.1 Source Enumerator Notes
* Sources INPUT_ID_USB0, INPUT_ID_BOSELINK1, INPUT_ID_BOSELINK2,
INPUT_ID_HDMI_FRONT, and INPUT_ID_HDMI_AV_FRONT are only available to
Room A.
