7.2 Key Press Codes
7.2.1 Hard Key Press Codes
These keys can be sent using the KP command. They will also be the values listed in Key Press
notification packets. These are also the codes received from an Infrared (IR) remote.
(See Sections 6.4 KP - Simulate a Key Press and 5.3.4.1 Key Press Notification Packets)
Table 7-2 Hard Key Press Codes
Key Name
Value
Explanation
Supported
Rooms
BOSE_MUTE
0x01
Toggles mute/unmute
All
BOSE_VOLUME_DOWN
0x02
Volume down
All
BOSE_VOLUME_UP
0x03
Volume up
All
BOSE_TUNER_SOURCE
0x06
Selects current Tuner Source
/Toggles Tuner band (second press)
B-O
BOSE_IPOD_SOURCE
0x07
Source Selection
All
BOSE_USB_SOURCE
0x08
Source Selection
A (Main)
BOSE_FRONT_HDMI_SOURCE
0x09
Source Selection
A (Main)
BOSE_FRONT_AV_SOURCE
0x0A
Source Selection
A (Main)
BOSE_PARTY
0x0D
Select Room A source
B-O
BOSE_TV_SOURCE
0x0E
Source Selection
All
BOSE_IPOD_OTHER
0x0F
Select IPOD or untyped sources
B-O
BOSE_INPUT_2
0x12
Source Selection
All
BOSE_INPUT_3
0x13
Source Selection
All
BOSE_LAST_CHANNEL
0x14
Previous channel
All
BOSE_INPUT_4
0x15
Source Selection
All
BOSE_CHANNEL_PRESET_DOWN
0x18
Channel/Preset down
All
BOSE_CHANNEL_PRESET_UP
0x19
Channel/Preset up
All
BOSE_STOP
0x1A
Depends on Source
All
BOSE_DOWN_ARROW
0x20
Menu navigation
A (Main)
BOSE_FM_SOURCE
0x25
Source Selection
†
All
BOSE_AM_SOURCE
0x28
Source Selection
†
All
BOSE_EXIT
0x30
Menu Navigation
A (Main)
BOSE_NUMBER_0
0x40
Numeric input
All
BOSE_NUMBER_1
0x41
Numeric input
All
BOSE_NUMBER_2
0x42
Numeric input
All
BOSE_NUMBER_3
0x43
Numeric input
All
BOSE_NUMBER_4
0x44
Numeric input
All
BOSE_NUMBER_5
0x45
Numeric input
All
BOSE_NUMBER_6
0x46
Numeric input
All
BOSE_NUMBER_7
0x47
Numeric input
All
BOSE_NUMBER_8
0x48
Numeric input
All
BOSE_NUMBER_9
0x49
Numeric input
All
