Bose COMPANION 20

6
I/O LABEL REPLACEMENT
Companion
®
20 I/O label replacement
Equipment Required
-Hot Air Gun
-Small Flat blade screw driver or dental pick
-New I/O Label, P/N 343766-0010
1. I/O label removal
1.1 Using a hot air gun, heat the I/O label
surface for 3 to 5 seconds.
1.2 Use a small flat head screwdriver or dental
pick to lift the top right corner of the label.
1.3 Once the right top corner is lifted, continue
lifting by hand to remove it fully away from the
assembly.
1.4 Remove all glue left on the assembly by
hand, then clean using a duster cloth.
2. I/O label replacement
2.1 Use Bose part number 343766-0010 as the
replacement I/O label.
2.2 Place the new label one the assembly
starting from the bottom.
2.3 Once the label is in place, apply an even
amount of pressure for 4 to 6 seconds across
all areas of the label.
