Installation and Operation Guide - 31
Technical Information
pro.Bose.com
Technical Specifications
Control Outputs
Outputs (Control) 5 digital outputs, 3.81 mm Euroblock, 6-pin
Output Voltage High: 8 V (open circuit), 2.5 V @ 10 mA
Low: < 1 V @ 100 mA, push-pull
Indicators and Controls
Display 256x64 OLED with rotary encoder
LED Status Indicators Power/Status
Audio Signal Indication On Display
Electrical Specifications
Mains Voltage 100 VAC - 240 VAC, 50/60 Hz
AC Power Consumption 35 W typical at 40 °C (104 °F) ambient
Mains Connector IEC 60320-C14 (Inlet)
Power Dissipation 60 W (205 BTU, 52 kcal)
Physical
Dimensions (H x W x D) 44 mm x 483 mm x 282 mm (1.7” x 19” x 11.1”)
Net Weight 3.6 kg (7.3 lb)
Operating Temperature 0°C - 40°C (32°F - 104°F)
Cooling System 2 variable speed fans, side venting
General
PC Configuration Software ControlSpace® Designer
TM
software
Network Control Ethernet (RJ-45), 1 Gb
RS-232/485 Ports RS-232 (DTE) and Bose CC-16 (RS-485 master) - 3.81 mm Euroblock,
3-pin
Audio Channel Capacity 166 (20 analog, 8 AmpLink out, 64x64 Dante, 4 VoIP, 4 USB, 2 PSTN)
Limited Warranty
Your product is covered by a limited warranty, Visit pro.Bose.com for warranty details.
The warranty information provided with this product does not apply in Australian and New Zealand. See our
website at www.bose.com/au/warranty or www.bose.com/nz/warranty for details of the Australian and New
Zealand warranty.
Audinate® and Dante® are registered trademarks of Audinate Pty Ltd.
Crestron® is a registered trademark of Crestron Electronics, Inc.
AMX® is a registered trademark of Harmon, International.
Refer to the owner’s guide at pro.Bose.com for more information about this product, including accessories and
replacement parts. To request a printed copy, use the phone numbers provided.
Date of Manufacture: The eighth digit in the serial number indicates the year of manufacture; “7” is 2007 or 2017.
