6
English
Installation
2.3 Mounting the bracket
Choose a position and mounting method consistent with local
building codes and regulations. Use two screws per bracket.
• Wall-mount option • Ceiling-mount • Mounting footprint
option
2.4 Attaching and adjusting the speaker
Partially insert the screws into the speaker.
After adjusting the speaker angle, use a wrench to tighten the
mounting screws firmly, securing the bracket.
6.9"
(175.2 mm)
"
"
To Next Page
