Bose FreeSpace 32SE Installer's Guide

7
English
Specifications
3.0 Loudspeaker specifications
Frequency Range
90Hz to 16kHz (±3 dB)
Model 32SE Versions
Active Equalization
• 70V (1W, 2W, 4W, 8W, 16W, 32W taps)
• 100V (1W, 2W, 4W, 8W, 16W, 32W taps)
Passive Equalization
• 4Ω, 32W, no transformer
Sensitivity
Active Equalization
86dB-SPL @ 1W, 1m (pink noise)
Passive Equalization
86dB-SPL @ 1W, 1m (pink noise)
Maximum Acoustic Output
101dB-SPL @ 1m (pink noise)
101dB-SPL @ 1m (IEC noise)
Dispersion (-6dB point, average, 1-4kHz)
132
o
conical
Long-Term Power Handling
32W continuous
Mechanical Specifications
Dimensions: 6"H x 9"W x 5.6"D (15.2 cmH x 22.9 cmW x
14.1 cmD)
Weight: 5 lb (2.3 kg)
Connectors: 70V/100V, screw terminals; 4Ω hex-nut post terminals
Mounting Hardware Included: Quick install U-bracket and hardware
Additional Mounting Points: Two (2)
1
/
4
-20 inserts, 0.7" on bottom
