Bose FREESPACE BMA-125 User Manual

22
120V AMP PCB
Transistors
Miscellaneous
Reference
Designator
Description Part Number See Note
CR1, 2 ZENER, 5.1V,
1/4W
185355
CR3-9, 16, 19-21 RECTIFIER 185356
CR10, 11 ZENER, 15V,1W 185357
CR12-15
6 AMP, 200V 185358
CR17 ZENER, 12.0V 185359
CR18 ZENER, 22.0V 185360
Reference
Designator
Description Part Number See Note
Q1, 2, 3, 5, 13, 15 2N5210 185365
Q4 MPS-A93 185366
Q6 MPSU06 185367
Q7 MJE253 185368
Q8 2N5088 185369
Q9 2N5086 185370
Q10 MPSU56 185371
Q11 MJE243 185372
Q12 MPS6566 185373
Q15, 16 MPS6518 185374
Reference
Designator
Description Part Number See Note
(Q7,11) BRKT, HEAT
SINK, (2)
185375
(Q7, 11) LK WASH, #4,
SPLIT SR (2)
185376
(Q7, 11) NUT, 4-40 HEX,
DBL CHAM (2)
185377
K1
DPDT, 24V 185364
J1 12 PIN, FRICTION
LOCK
185361
J2 CONNECTOR 185362
J3 MOLEX, SQ
WIRE, 6 POS
185363
!
!
Diodes
