Bose FREESPACE BMA-125 User Manual

24
120V Tone/Volume Control PCB
Capacitors (continued)
Transistors
Integrated Circuits
Miscellaneous
Reference
Designator
Description Part Number See Note
C6 56 PF, 50V, CER,
20%
185420
C8,9 47 µF, 10V, ELCT,
RDL
185421
C10 10V, 680 µFD 185412
C13,14 .015 µF, 50V,
CER, 20%
185413
C15 220 PF, 50V,
CER, 20%
185414
C16 22 PF, 1KV, CER,
10%
185415
C17, 18, 19, 20 .01 µF, 50V, CER,
20%
185416
C21, 22 33 µF, 25V, ELCT
RDL
185418
Reference
Designator
Description Part Number See Note
Q1 2N5088 185369
Q2 VN0300M 185423
Reference
Designator
Description Part Number See Note
U1, 2 LM833 185474
Reference
Designator
Description Part Number See Note
(Q5, 6) BRKT, HTSNK 185425
(Q5, Q6, U2, U3) LK WASH, 4
SPLT SPRING
185426
(Q5, Q6, U2, U3) NUT, 4-4- HEX
DBL CHAM
185427
(U2, 3) HEATSINK W/
LEGS
185428
(U2, 3) SCR 4-40 X 5/16 185429
