30
Reference
Designator
Description Part Number See Note
Q1 MPS-A93 185465
Q2 2N5551 185466
Q3, 6 MJE340 185467
Q4, 5 MJE350 185468
Q7, 16 2N5088 185469
Q8, 15 2N5086 185470
Q9 2N3904 185471
Q10, 11 2N3906 185472
Q12, 13 2N5210 185473
Reference
Designator
Description Part Number See Note
U1 LM833 185474
U2 7815 185475
U3 7915 185476
Reference
Designator
Description Part Number See Note
CR1, 2, 5-7, 17-
21, 28-34, 37
SILICON 185477
CR8, 9-14 RECTIFIER,
IN4937
185478
CR3, 4 ZENER, 9.1V 185479
CR15, 16 3A, 200V 185480
CR22 ZENER, 10V 185481
CR23, 24, 26, 27 6A, 200V 185482
!
Transistors
Integrated Circuits
Diodes
230V AMP PCB
