Bose FreeSpace FS4CE User Manual

English • 3Installation Guide • FreeSpace FS4CE
PRO.BOSE.COM
Overview
Package Contents
Product Dimensions
×2 ×2 ×1
Technical Specifications
For additional specifications, see the FreeSpace FS4CE
technical data sheet at PRO.BOSE.COM. For EN 54-24
specifications, see the FreeSpace FS4CE EN 54-24 certified
ratings (AM857614 Rev. 00) at PRO.BOSE.COM.
Physical
Product Dimensions Bae diameter: 272 mm
(10.71 in)
Enclosure diameter: 231 mm
(9.09 in)
Backcan depth: 163 mm
(6.42 in)
Hole cutout 250 mm (9.84 in)
Maximum Ceiling Thickness 38 mm (1.50 in)
Net Weight, Loudspeaker
with grille (single)
3.47 kg (7.65 lb)
Shipping Weight (pair) 9.05 kg (19.95 lb)
Environmental Suitable for use outdoors in wet
locations with included weather-
resistant input cover (IP55 per
EN60529; IP33C per EN 54-24).
Optional accessory aluminum
grille for harsh environments to
prevent red corrosion is available.
Important Installation Information
Before installing the loudspeaker, review
Important Safety Instructions on page 2.
For fire and evacuation notification applications,
environmental rated to IP33C per EN 54-24.
For general purpose audio installation
applications, environmental rated to IP55 per
EN60529.
239 mm
9.41 in
272 mm
10.71 in
171 mm
6.73 in
38 mm
1.50 in
163 mm
6.42 in
231 mm
9.09 in
×2 ×2×4

Bose FreeSpace FS4CE Specifications

General

Speaker type	Full range
Driver diameter	114 mm
Number of drivers	1
Speaker placement	Ceiling-mountable
Audio output channels	- channels
Impedance	8 Ω
Sensitivity	88 dB
Frequency range	70 - 17000 Hz
RMS rated power	40 W
Peak Music Power Output (PMPO)	160 W
Backlight	No
Certification	UL 1480, ULC-S541 NFPA 70, NFPA 72, CSA C22.1 Section 32 IEC60268-5, CE RoHS
Product color	White
Housing material	Plastic, Steel
Recommended usage	Universal
Suitable for outdoor use	Yes
Connectivity technology	Wired
Operating temperature (T-T)	-25 - 70 °C
Package weight	9050 g
Transformer taps	2.5, 5, 10, 20, 40 W

Weight and Dimensions

Width	272 mm
Height	172 mm
Weight	3470 g
