Bose FreeSpace FS4CE User Manual

4 • English FreeSpace FS4CE • Installation Guide
PRO.BOSE.COM
Setup
Installation Options
Installation Options and Accessories
One of the following is required for installation. See the
related accessory installation guide at PRO.BOSE.COM for
installation instructions.
q Adjustable Tile Bridge (not included)
w Rough-in Pan (not included)
Conduit Fitting
If using a flexible metal conduit, use with a ⅜-inch conduit
fitting or a ⅜-inch dual (duplex) connector.
Note: Conduit fittings are not provided.
q
w
Choosing an Installation Method
q Top Knockout
Use the top knockout when there is available space above the ceiling.
w Side Knockout
Use the side knockout when there is limited space above the ceiling.
e Both Knockouts
Use both knockouts when an independent signal-in and signal-out wiring scheme is required and there is available space
above the ceiling.
q w e
⅜-inch single in ⅜-inch duplex in/loop

Bose FreeSpace FS4CE Specifications

General

Speaker type	Full range
Driver diameter	114 mm
Number of drivers	1
Speaker placement	Ceiling-mountable
Audio output channels	- channels
Impedance	8 Ω
Sensitivity	88 dB
Frequency range	70 - 17000 Hz
RMS rated power	40 W
Peak Music Power Output (PMPO)	160 W
Backlight	No
Certification	UL 1480, ULC-S541 NFPA 70, NFPA 72, CSA C22.1 Section 32 IEC60268-5, CE RoHS
Product color	White
Housing material	Plastic, Steel
Recommended usage	Universal
Suitable for outdoor use	Yes
Connectivity technology	Wired
Operating temperature (T-T)	-25 - 70 °C
Package weight	9050 g
Transformer taps	2.5, 5, 10, 20, 40 W

Weight and Dimensions

Width	272 mm
Height	172 mm
Weight	3470 g
