Bose MB210 - Input Panel

English • 13
Installation Guide • MB210/MB210-WR
PRO.BOSE.COM
Overview
Input Panel
MB210
q Euroblock Connector (4-pin)
w NL4 connectors
MB210-WR
The input panel for the MB210-WR includes a single screw-terminal barrier strip. Each terminal accepts a wire
gauge of 10 AWG to 18 AWG.
+
–
+
–
LF
INPUT
THRU
q Barrier strip
q w
q
