18 • English
MB210/MB210-WR • Installation Guide
PRO.BOSE.COM
Technical Specifications
Technical Specifications
MB210
System Performance
Frequency Response (±3 dB)
1
45 to 180 Hz
Frequency Range (–10 dB) 37 to 270 Hz
Nominal Coverage Pattern (H × V) Omni-directional below 200 Hz
Recommended High-pass Filter 45 Hz with 24-dB/octave filter
Crossover 80 to 200 Hz (requires active crossover in DSP)
Bose Extended Lifecycle Test
2
AES Transducer Test
3
Power Handling, long-term continuous 500 W 625 W
Power Handling, peak 2000 W 2500 W
Free Field Half-space Free Field Half-space
Sensitivity (SPL / 1 W @ 1 m)
4
90 dB 96 dB 90 dB 96 dB
Calculated Maximum SPL @ 1 m
5
117 dB 123 dB 118 dB 124 dB
Calculated Maximum SPL @ 1 m, peak 123 dB 129 dB 124 dB 130 dB
Transducers
Low Frequency 2 × Bose 10-inch, high-excursion woofers
Nominal Impedance 8 Ώ
Physical
Enclosure Material Baltic birch plywood
Finish Polyurethane coating, black or white
Grille Powder-coated perforated steel
Environmental Indoor only
Connectors 2 × Neutrik® NL4 with 4-pin Euroblock, all wired parallel
Suspension/Mounting 3 × M8 threaded inserts for U-bracket (per side)
Dimensions (H × W × D) – millimeters 291 × 685 × 482 with U-bracket
Dimensions (H × W × D) – inches 11.5 × 27.0 × 19.0 with U-bracket
Net Weight (loudspeaker only) 18.6 kg (41.0 lb)
Net Weight (with U-bracket) 21.8 kg (48.0 lb)
Shipping Weight 27.2 kg (59.9 lb)
Accessories Included steel U-bracket and 4 × adhesive-mounted rubber ground-stack feet
Footnotes
1. Frequency response and range measured on-axis in anechoic environment with recommended bandpass and EQ.
2. Bose extended-lifecycle test using pink noise filtered to meet IEC268-5, 6-dB crest factor, 500-hour duration.
3. AES standard 2-hour duration with IEC system noise.
4. Sensitivity measured in anechoic environment with recommended bandpass and EQ.
5. Maximum SPL calculated using sensitivity and power ratings, exclusive of power compression.
