Installation
Using the Ground Feet
The MB210 subwoofer can be placed on the ground in either the horizontal or vertical orientation, using the
ground feet. To attach the ground feet:
1. Remove the backing from the adhesive side of the first ground foot.
2. Position the ground foot in one corner of the loudspeaker, on the side that will be resting on the floor. See
the figures below.
3. Press the adhesive side of the ground foot onto the loudspeaker to adhere.
4. Repeat steps for the remaining three ground feet.
Ground feet position for horizontal orientation
Ground feet position for vertical orientation
