Part List
Panaray
®
MA12 Loudspeaker Protection Circuit Board (see Figure 3)
Figure 3. MA12 Protection Circuit Board Layout Diagram
Item
Number
Description Part Number Qty. Note
PCB ASSY, PROTECTION CKT 298553 1
1 LAMP, GREEN DOT 298554 2
2 POLYSWITCH, RXE075 298555-075 1
