Bose S1 Pro - Dual-Mono;Daisy-Chain Setup

English • 15Owner's Guide • S1 Pro System
System Setup
Dual-Mono/Daisy-Chain
Link two S1 Pro systems together in mono by using a TRS ¼" cable. Take the line out of the primary unit and
plug it into the secondary S1 Pro system. Turn the channel volume up until both units are at desired volume.
SIGNAL SIGNAL SIGNAL
123
SIGNAL SIGNAL SIGNAL
123
Note: On secondary units, set ToneMatch® and reverb to o and leave tone controls at center detent position.
