Bose Solo 10 Service Manual

4
Product Overview
The Bose
®
Solo 15/10 system is designed to fit under TVs that weigh no more than 75 lbs (34 kg) and have bases
no wider than 24" (61 cm), and no deeper than 12.25" (31 cm).
The Bose Solo 15 has a metal grille and is packaged with a universal remote.
The Bose Solo 10 has a cloth grille and is packaged with a 4 button remote.
The enclosure contains 5 drivers, which are not shielded, an amplifier/power supply and IR PCB.
Power rating: 100-240V 50/60 Hz 50W
Dimensions: 24.75" (62.8 cm) W x 14" (35.6 cm) D x 3" (7.6 cm) H
Weight: 12 lbs (6.35 kg)
Connections:
Audio inputs: Optical, Coax, Analog
USB: Used for software updates
3.5 mm jack: Data connection is used for test (TAP) access.
Tone Controls:
Bass control knob - located on rear
Dialog Mode:
Press the dialog mode button on the remote
The system status indicator will blink amber three times and then remain amber
To exit dialog mode, press the dialog button again. The system status indicator blinks green three times and
then remains green
System status (indicator located center front on unit):
Indicator System State
Off System off (standby)
Dim amber Standby, auto wake is
enabled
Solid green Power is on
Blinking green
or
Blinking amber
(if dialog mode is
enabled)
System is muted
Fast blinking green
or
Fast blinking amber
(if dialog mode is
enabled)
Volume is being adjusted
Solid amber Dialog mode is enabled
Solid red System error

Bose Solo 10 Specifications

General

Brand	Bose
Model	Solo 10
Category	Stereo System
Language	English
