Bose SoundDock 10 Owner's Guide

2
THE SOUNDDOCK
®
10 DIGITAL MUSIC SYSTEM
EnglishTAB 6, 14TAB 8, 16 TAB 7, 15 TAB 3, 11TAB 5, 13 TAB 2, 10TAB 4, 12
Setting up your system
1. Place your SoundDock 10 digital music system on a
flat, stable surface.
2. Plug the small end of the AC power cord into the AC
power connector on the back of the unit.
3. Plug the other end into a live AC (mains) outlet. After
you hear two short tones from your SoundDock 10
system, it is ready to use.
CAUTION: Do not cover the ventilation openings of the
product. The slots on the top provide ventilation for the
built-in electronic circuitry and shall not be blocked.
Note: When handling the SoundDock 10 system, the front
structure containing the iPod dock may feel loose. This is normal.
This part of the system is intentionally designed to prevent
speaker vibration from interferring with the operation of your iPod.
System on/off control
You can turn on your SoundDock 10 system in any of the
following three ways:
• Dock a device.
• Press any key except OFF on the Bose
®
remote.
• Press any key on the docked device.
To turn off the SoundDock 10 system, do either one of
the following:
• Press OFF on the SoundDock 10 remote.
• Remove the docked device.
AC IN

Bose SoundDock 10 Specifications

General

Frequency range	- Hz
RMS rated power	- W
Audio output channels	- channels
Bluetooth	Yes
Composite video out	1
Headphone connectivity	-
FM radio	No
Apple docking compatibility	iPhone, iPod
Dimensions (WxDxH)	432 x 244 x 221 mm
Cables included	AC
Product color	Silver

Weight and Dimensions

Weight	8400 g
