Bose SoundLink Mini

10
Reference
Designator
Description Material Number Note
R506
RES, 0402, 63MW, 1%, 1K 268361-1001
R507 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R508 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R509 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R510 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R511 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R512 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R513 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R514 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R515 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R516 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R517 RES, 0402, 63mw, 1%, 2.49K 268361-2491
R518 RES, 0402, 63MW, 1%, 100K 268361-1003
R519 RES, 0402, 63MW, 1%, 1K 268361-1001
R520 RES, 0402, 63MW, 1%, 49.9 OHM 268361-49R9
R521 RES, 0402, 63MW, 1%, 100K 268361-1003
R522 RES, 0603, .1W, 1%, 150 OHMS 191465-1500
R523 RES, 0603, .1W, 1%, 150 OHMS 191465-1500
R524 RES, 0603, .1W, 1%, 150 OHMS 191465-1500
R525 RES, 0603, .1W, 1%, 150 OHMS 191465-1500
R526 RES, 0603, .1W, 1%, 150 OHMS 191465-1500
R527 RES, 0402, 63MW, 1%, 100K 268361-1003
R528 RES, 0402, 63MW, 1%, 2.21K 268361-2211
R531 RES, 0603, .1W, 1%, 1 OHM 191465-01R0
R602 RES, 0402, 63MW, 1%, 100K 268361-1003
R603 RES, 0402, 63MW, 1%, 10K 268361-1002
R604 RES, 0402, 0.063W, 1%, 332K 268361-3323
R605 RES, 0402, 63MW, 1%, 100K 268361-1003
R701 RES, 0402, 0.063W, 1%, 681K 268361-6813
R702 RES, 0402, 63MW, 1%, 1K 268361-1001
R703 RES, 0402, 63MW, 1%, 4.99K 268361-4992
R704 RES, 0402, 63MW, 1%, 64.9K 268361-6492
R705 RES, 0402, 63MW, 1%, 49.9K 268361-4992
R706 RES, 0402, 63MW, 1%, 64.9K 268361-6492
R707 RES, 0402, 63MW, 1%, 499 268361-499R
R708 RES, 0402, 63MW, 1%, 499 268361-499R
R709 RES, 0402, 0.063W, 1%, 30.1 OHMS 268361-30R1
R710 RES, 0402, 0.063W, 1%, 30.1 OHMS 268361-30R1
R711 RES, 0402, 0.063W, 1%, 30.1 OHMS 268361-30R1
R712 RES, 0402, 0.063W, 1%, 30.1 OHMS 268361-30R1
R713 RES, 0402, 0.063W, 1%, 30.1 OHMS 268361-30R1
R714 RES, 0402, 0.063W, 1%, 30.1 OHMS 268361-30R1
R715 RES, 0402, 63MW, 1%, 4.99K 268361-4991
ELECTRICAL PART LIST
Main PCB
Resistors (continued)
