Bose SoundLink Mini

11
Reference
Designator
Description Material Number Note
R716
RES, 0402, 63MW, 1%, 4.99K 268361-4991
R717 RES, 0402, 63MW, 1%, 10K 268361-1002
R720 RES, 0402, 63MW, 1%, 4.99K 268361-4992
R721 RES, 0402, 63MW, 1%, 4.99K 268361-4992
R722 RES, 0402, 63MW, 1%, 2.21K 268361-2213
R723 RES, 0402, 63MW, 1%, 1M 268361-1004
R801 RES, 0402, 63MW, 1%, 1K 268361-1001
R802 RES, 0402, 63MW, 1%, 10K 268361-1002
R803 RES, 0402, 63MW, 1%, 10K 268361-1002
R805 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R806 RES, 0603, .1W, 1%, 20 OHM 191465-20R0
R807 RES, 0402, 63MW, 1%, 1K 268361-1001
R808 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R809 RES, 0402, 63MW, 1%, 10K 268361-1002
R810 RES, 0402, 63MW, 1%, 10K 268361-1002
R811 RES, 0402, 63MW, 1%, 10K 268361-1002
R812 RES ,0603, .1W, 1%, 20 OHM 191465-20R0
R813 RES, 0402, 63MW, 1%, 1K 268361-1001
R814 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R815 RES, 0402, 63MW, 1%,10 OHM 268361-10R0
R816 RES, 0603, 0.1W, 1%, 12OHMS 191465-12R0
R817 RES, 0402, 63MW, 1%, 1K 268361-1001
R819 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R820 RES, 0603, .1W, 1%, 33 OHM 191465-33R0
R825 RES, 0603, .1W, 1%, 75 OHM 191465-75R0
R827 RES, 0603, .1W, 1%, 75 OHM 191465-75R0
ELECTRICAL PART LIST
Main PCB
Resistors (continued)
