Bose SoundLink Mini

12
Reference
Designator
Description Material Number Note
C302 CAP, X5R, 0402, 20%, 6.3V, 2.2uF 313771-225JM
C303 CAP, X5R, 0603, 2.2uF, 16V, 20% 313766-225C
C304 CAP, X5R, 0402, 20%, 6.3V, 2.2uF 313771-225JM
C305 CAP, X5R, 0402, 10V, 10%, 0.47uF 342199-474
C306 CAP, COG, 0402, 5%, 15pF, 50V 268364-150
C307 CAP, X7R, 0402, 50V, 5%, 10 nF 268366-103
C308 CAP, X7R, 0402, 50V, 5%, 10 nF 268366-103
C309 CAP, X5R, 0402, 10V, 10%, 0.47uF 342199-474
C310 CAP, X5R, 0402, 0.1uF, 16V, 10% 313771-104C
C311 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C312 CAP, X5R, 0402, 0.1uF, 16V, 10% 313771-104C
C314 CAP, X5R, 0402, 20%, 6.3V, 2.2uF 313771-225JM
C316 CAP, X5R, 0603, 4.7uF, 6.3V, 20% 313766-475J
C317 CAP, X5R, 0402, 0.1uF, 16V, 10% 313771-104C
C318 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C319 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C320 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C321 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C322 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C323 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C324 CAP, X5R, 0603, 2.2uF, 16V, 20% 313766-225C
C325 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C326 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C327 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C328 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C401 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C402 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C403 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C404 CAP, 1206, X7R, LD, 25V, 10%, 1uF 306105-105
C405 CAP, 1206, X7R, LD, 25V, 10%, 1uF 306105-105
C406 CAP, 1206, X7R, LD, 25V, 10%, 1uF 306105-105
C407 CAP, X7R, 0402, 50V, 5%, 1nF 268366-102
C408 CAP, X7R, 0402, 50V, 5%, 1nF 268366-102
C409 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C410 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C412 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C414 CAP, X7R, 0402, 10V, 10%, 0.1uF, COMM 718866-104K1A
C415 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C416 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C417 CAP, 1206, X7R, LD, 25V, 10%, 1uF 306105-105
C419 CAP, X7R, 0603, 1uF, 16V, 10% 257154-105K16
C420 CAP, X7R, 0402, 10V, 10%, 0.1uF, COMM 718866-104K1A
C421 CAP, X5R, 0603, 6.3V, 20%, 22uF, COMM 718835-226M0J
ELECTRICAL PART LIST
Main PCB
Capacitors
