Bose SoundLink Mini

13
Reference
Designator
Description Material Number Note
C422 CAP, X7R, 0402, 10V, 10%, 0.1uF, COMM 718866-104K1A
C423 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C424 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C425 CAP, X7R, 0402, 10V, 10%, 0.1uF, COMM 718866-104K1A
C502 CAP, X7R, 0402, 16V, 10%, 0.1uF, COMM 718866-104K1C
C504 CAP, X7R, 0402, 16V, 10%, 0.1uF, COMM 718866-104K1C
C505 CAP, X7R, 0402, 16V, 10%, 0.1uF, COMM 718866-104K1C
C506 CAP, X7R, 0402, 16V, 10%, 10000pF, COMM 718866-103K1C
C507 CAP, CER, 1210, X7R, 25V, 10uF 291431-106
C508 CAP, 1206, X7R, 25V, 10%, 4.7uF 262063-475
C509 CAP, X7R, 0402, 16V, 10%, 0.1uF, COMM 718866-104K1C
C511 CAP, CER, 1210, X7R, 25V, 10uF 291431-106
C512 CAP, X7R, 0402, 16V, 10%, 0.1uF, COMM 718875-104K1C
C513 CAP, X7R, 0402, 16V, 10%, 1000pF, COMM 718866-102K1C
C603 CAP, X5R, 0805, 25V, 10%, 10uF 273592-106E
C604 CAP, 0805, X7R, 50V, 0.33uF 133623-334
C605 CAP, X5R, 0805, 22uF, 6.3V, 20% 273592-226JM
C608 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C610 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C701 CAP, X5R, 0805, 22uF, 6.3V, 20% 273592-226JM
C702 CAP, 0805, X7R, 10%, 25V, 1uF 181264-105
C703 CAP, X5R, 0402, 0.1uF, 16V, 10% 313771-104C
C704 CAP, X5R, 0402, 0.1uF, 16V, 10% 313771-104C
C705 CAP, X5R, 0402, 0.1uF, 16V, 10% 313771-104C
C706 CAP, X5R, 0402, 0.1uF, 16V, 10% 313771-104C
Diodes
Reference
Designator
Description Material Number Note
D401 DIODE, SWITCHING, 100V, BAV99, SOT363 319113-001
D402 DIODE, SWITCHING, 100V, BAV99, SOT363 319113-001
D403 DIODE, SWITCHING, 100V, BAV99, SOT363 319113-001
D502 DIODE, SCHOTTKY, 40V, 3A, SMB 193847-001
D503 DIODE, SCHTKY, SC70, 30V, SERIES 268381-004
D601 DIODE, SCHTKY, SC70, 30V, COM.CATH 268381-003
D602 DIODE, SCHTKY, SC70, 30V, COM.CATH 268381-003
D701 DIODE, SOT-23, BAV99 147239
D702 DIODE, SCHTKY, SC70, 30V, COM.CATH 268381-003
DS801 DIODE, LED, 0402, 0.01A, 5V, VERT, WHITE 373123-0010
DS802 DIODE, LED, 0402, 0.01A, 5V, VERT, WHITE 373123-0010
DS803 DIODE, LED, 0603, 0.20A, 5V, BLUE 728316-0020
DS805 DIODE, LED, 0402, 0.02A, 5V, GRN 364327-0020
DS807 DIODE, LED, 0402, 0.02A, 5V, YELLOW 367495-0020
DS808 DIODE, LED, 0402, 0.02A, 4V, RED 367495-0010
ELECTRICAL PART LIST
Main PCB
Capacitors Continued
