Bose SoundLink Mini

14
Reference
Designator
Description Material Number Note
Q501 TRANSISTOR, MOSFET, P-CH, 0.3A, 30V, DMP32D4S 736331-0010
Q502 TRANSISTOR, BRT, NPN, 4.7K/47K, SOT-23 346223-0010
Q503 TRANSISTOR, BRT, NPN, 4.7K/47K, SOT-23 346223-0010
Q504 TRANSISTOR, MOSFET, P-CH, 4A, 20V, SOT-23 626239-0010
Q505 TRANSISTOR, BRT, NPN, 4.7K/47K, SOT-23 346223-0010
Q506 XSISTOR, BPLR, P, 40V, 200mA, SOT23 148596
Q601 XSISTOR, BPLR, N, 40V, 200mA, SOT23 146819
Q602 TRANSISTOR, MOSFET, P-CH, 0.3A, 30V, DMP32D4S 736331-0010
Q701 TRANSISTOR, MFET, N-CH, 0.3A, 60V, SOT-23 356154-0010
Q801 TRANSISTOR, BPLR, NPN, 0.2A, 40V, SOT-363 195857-3
Q802 TRANSISTOR, BPLR, NPN, 0.2A, 40V, SOT-363 195857-3
Q803 TRANSISTOR, BPLR, NPN, 0.2A, 40V, SOT-363 195857-3
Q804 TRANSISTOR, BPLR, NPN, 0.2A, 40V, SOT-363 195857-3
Integrated Circuits
Reference
Designator
Description Material Number Note
U200 IC, SoC,BLUETOOTH, W/DSP, CSR8670C, 112VFBGA 354008-0010
U202 IC, MEM, FLASH, SERIAL, 32Mb, 1.8V, 8SO 716603-0010
U501 IC, BATT CHRG, LI-ION, USB, 2-CELL, 5V, 20CSP 715728-0010
U602 IC, VREG, SW, BUCK, 0.5A, 3.3V, TPS62172, 8WSON 715991-0010
U701 IC, SoC, ARM, 32b, 85C, 4V, STM32F030C6, 48LQFP 715757-0020
Miscellaneous
Reference
Designator
Description Material Number Note
FB501 BEAD, FERRITE, 0603, 6A, 26 OHMS 345337-S026
FB502 BEAD, FERRITE, 0603, 6A, 26 OHMS 345337-S026
FL301 FILTER, SAW, 2.4GHz, BLUETOOTH, SON-5 331796-0010
J902 CONN, BRD-BRD, MALE, T ENTRY, 20POS, GRY 357552-0020
J903 CONN, FFC, 0.5mm, S ENTRY, 34POS 363842-34S2
L301 INDUCTOR, POWER, SMT, 85C, 1A, 20%, 4.7uH 627684-4R7M
L302 INDUCTOR, POWER, SMT, 85C, 1A, 20%, 4.7uH 627684-4R7M
L501 INDUCTOR, SMT, 6X6mm, 2.6A, 20%, 4.7uH 369623-4R7M
L601 INDUCTOR, POWER, SMT, 85C, 1.2A, 20%, 3.3uH 716046-3R3M
S801 SWITCH, TACT, SPST, 50mA, 12V, SMT 364142-0010
S802 SWITCH, TACT, SPST, 50mA, 12V, SMT 364142-0010
S804 SWITCH, TACT, SPST, 50mA, 12V, SMT 364142-0010
S805 SWITCH, TACT, SPST, 50mA, 12V, SMT 364142-0010
S806 SWITCH, TACT, SPST, 50mA, 12V, SMT 364142-0010
W201 JUMPER, 0402, 0 OHM 280043
W202 JUMPER, 0402, 0 OHM 280043
ELECTRICAL PART LIST
Main PCB
Transistors
