Bose SoundLink Mini

15
Reference
Designator
Description Material Number Note
W301 JUMPER, 0402, 0 OHM 280043
W302 JUMPER, 0402, 0 OHM 280043
W402 JUMPER, 0402, 0 OHM 280043
W403 JUMPER, 0402, 0 OHM 280043
W404 JUMPER, 0402, 0 OHM 280043
W405 JUMPER, 0402, 0 OHM 280043
W408 JUMPER, 0402, 0 OHM 280043
W409 JUMPER, 0402, 0 OHM 280043
W412 JUMPER, 0402, 0 OHM 280043
W413 JUMPER, 0402, 0 OHM 280043
W414 JUMPER, 0402, 0 OHM 280043
W416 JUMPER, 0402, 0 OHM 280043
W703 JUMPER, 0402, 0 OHM 280043
W704 JUMPER, 0402, 0 OHM 280043
X301 CRYSTAL, 26MHz, +/-10ppm, SMD 291429-008
Reference
Designator
Description Material Number Note
R500 RES, 0402, 63MW, 1%, 100K 268361-1003
R501 RES, 0402, 63MW, 1%, 100K 268361-1003
R502 RES, 0402, 63MW, 1%, 22.1K 268361-2212
R505 RES, 0402, 63MW, 1%, 100K 268361-1003
R508 RES, 0402, 63MW, 1%, 100K 268361-1003
R509 RES, 0402, 33.2K, 1/16W, 1% 268361-3322
R510 RES, 0402, 63MW, 1%, 100K 268361-1003
R511 RES, 0402, 63MW, 1%, 280K 268361-2803
R512 RES, 0402, 63MW, 1%, 27.4K 268361-2742
R513 RESISTOR, JUMPER, 2A, 1206 319408-001
R514 RES, 0402, 63MW, 1%, 1.00K 268361-1001
R515 RES, METAL FOIL, 1206, 0.5W, 1%, 0.005 OHM 626686-R005F
R516 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R517 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R518 RES, 0805, 1/10W, 5%, 2.7 OHM 133626-2R75
R519 RES, 0402, 47.5K, 1/16W, 1% 268361-4752
R520 RES, 0402, 47.5K, 1/16W, 1% 268361-4752
R521 RES, 0402, 63MW, 1%, 499K 268361-4993
R522 RES, 0402, 63MW, 1%, 22.6K 268361-2262
R523 RES, 0402, 63MW, 1%, 3.01K 268361-3011
R524 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R525 RES, 0402, 63MW, 1%, 150K 268361-1503
R526 RES, 0402, 63MW, 1%, 499K 268361-4993
ELECTRICAL PART LIST
Main PCB
Miscellaneous Continued
Boost PCB Part List
Resistors
