Bose SoundLink Mini

16
Reference
Designator
Description Material Number Note
C400 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C401 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C501 CAP, 0603, X7R, 50V, 10%, .033uF 191470-333
C502 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C503 CAP, C0G, 0402, 50V, 5%, 1.2nF 268364-122
C504 CAP, X5R, 0805, 25V, 10%, 10uF 273592-106E
C505 CAP, COG, 0402, 50V, 5%, 68pF 268364-680
C506 CAP, X7R, 0603, 1uF, 16V, 10% 257154-105K16
C507 CAP, X5R, 0805, 25V, 10%, 10uF 273592-106E
C508 CAP, X7R, 0603, 10%, 0.1uF, 50V 304991-104
C509 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C510 CAP, X5R, 0805, 25V, 10%, 10uF 273592-106E
C511 CAP, X5R, 0805, 25V, 10%, 10uF 273592-106E
C512 CAP, C0G, 0402, 50V, 5%, 1.5nF 268364-152
C513 CAP, X7R, 10UF, 25V, SMD, 125C, FT 315052-106D
C515 CAP, X7R, 0402, 25V, 5%, 3.3nF 268367-332
Diodes
Reference
Designator
Description Material Number Note
D500 DIODE, DUAL, 75V, 300mA, SOT-23 148774
D501 DIODE, SOT-23, BAV99 147239
D503 DIODE, SCHOTTKY, 10A, 40V, SMT 350300-0020
D504 DIODE, SCHTKY, SC70, 30V, SINGLE 268381-001
Transistors
Reference
Designator
Description Material Number Note
Q500 XISTOR, MFET, N-CH, 0.3A, 60V, 2N7002K, AUTO-Q 356154-0020
Q501 XISTOR, MFET, N-CH, 0.3A, 60V, 2N7002K, AUTO-Q 356154-0020
Q502 XISTOR, MFET, N-CH, 0.3A, 60V, 2N7002K, AUTO-Q 356154-0020
Q503 XISTOR, MOSFET, P-CH, 4A,20V, SOT-23 626239-0010
Q504 XISTOR, MFET, N-CH, 0.3A, 60V, 2N7002K, AUTO-Q 356154-0020
Q505 XISTOR, MFET, N-CH, 0.3A, 60V, 2N7002K, AUTO-Q 356154-0020
Q506 XISTOR, MFET, N-CH, 21A, 25V, 8SON 357501-0010
Q507 XISTOR, BPLR, P, 40V, 200mA, SOT23 148596
ELECTRICAL PART LIST
Boost PCB
Capacitors
