17
Reference
Designator
Description Material Number Note
U500 IC, BOOST CONTROLLER, 4.5V TO 52V, 10SON 327304-0020
Miscellaneous
Reference
Designator
Description Material Number Note
J400 CONN, BRD-BRD, FEMALE, S ENTRY, 20 POS, GRY 357586-20S1
J401 CONN,BRD-BRD,FEMALE,S ENTRY,20 POS,GRY 357586-20S1
L500 INDUCTOR, SMT, 11.4X10.8mm, 13.6A, 20%, 2.2uH 628640-2R2M
Reference
Designator
Description Material Number Note
R200 RES, 0402, 63MW, 1%, 249 OHM 268361-2490
R201 RES, 0402, 63MW, 1%, 249 OHM 268361-2490
R202 RES, 0402, 63MW, 1%, 249 OHM 268361-2490
R203 RES, 0402, 63MW, 1%, 249 OHM 268361-2490
R300 RES, 0402, 63MW, 1%, 100K 268361-1003
R302 RES, 0402, 63MW, 1%, 100K 268361-1003
R303 RES, 0603, .1W, 1%, 20K 191465-2002
R304 RES, 0603, .1W, 1%, 100K 191465-1003
R305 RES, 0402, 63MW, 1%, 10 OHM 268361-10R0
R306 RES, 0402, 63MW, 1%, 1K 268361-1001
Reference
Designator
Description Material Number Note
C200 CAP, COG, 0402, 5%, 1000pF, 50V 268366-102
C201 CAP, COG, 0402, 5%, 1000pF, 50V 268366-102
C202 CAP, X7R, 0402, 50V, 10%, 1500pF, COMM 718866-152K1H
C203 CAP, X7R, 0402, 50V, 10%, 1500pF, COMM 718866-152K1H
C204 CAP, X7R, 0402, 50V, 10%, 1500pF, COMM 718866-152K1H
C205 CAP, X7R, 0402, 50V, 10%, 1500pF, COMM 718866-152K1H
C300 CAP, 1206, X7R, LD, 25V, 10%, 1.0uF 306105-105
C301 CAP, 1206, X7R, LD, 25V, 10%, 1.0uF 306105-105
C302 CAP, 1206, X7R, LD, 25V, 10%, 1.0uF 306105-105
C303 CAP, 1206, X7R, LD, 25V, 10%, 1.0uF 306105-105
C304 CAP, X7R, 0603, 1uF, 16V, 10% 257154-105K16
C305 CAP, 1206, X7R, 50V, 1uF, 10% 286500-105
C306 CAP, 0805, X7R, 50V, 10%, 0.22uF 133623-224
Capacitors
ELECTRICAL PART LIST
Boost PCB
Integrated Circuits
Amp PCB Part List
Resistors
