18
Reference
Designator
Description Material Number Note
C307 CAP, 0805, X7R, 50V, 10%, 0.22uF 133623-224
C308 CAP, 0805, X7R, 50V, 10%, 0.22uF 133623-224
C309 CAP, 0805, X7R, 50V, 10%, 0.22uF 133623-224
C310 CAP, COG, 0402, 5%, 1000pF, 50V 268364-102
C311 CAP, COG, 0402, 5%, 1000pF, 50V 268364-102
C312 CAP, X7R, 0603, 10%, 0.1uF, 50V 304991-104
C313 CAP, X7R, 0603, 10%, 0.1uF, 50V 304991-104
C315 CAP, X7R, 0603, 10%, 0.1uF, 50V 304991-104
C317 CAP, X7R, 0603, 10%, 0.1uF, 50V 304991-104
C320 CAP, 1206, X7R, 50V, 1.0uF, 10% 286500-105
C321 CAP, 1206, X7R, 50V, 1.0uF, 10% 286500-105
C322 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C323 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C324 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C325 CAP, 1206, X7R, 50V, 1.0uF, 10% 286500-105
C327 CAP, COG, 0402, 5%, 100pF, 50V 268364-101
C328 CAP, X7R, 10uF, 25V, SMD, 125C, FT 315052-106D
C329 CAP, X7R, 10uF, 25V, SMD, 125C, FT 315052-106D
C330 CAP, X7R, 10uF, 25V, SMD, 125C, FT 315052-106D
Integrated Circuits
Miscellaneous
Reference
Designator
Description Material Number Note
FB300 BEAD, FERRITE, 1806, 6A, 100 OHM 722888-0010
FB301 BEAD, FERRITE, 1806, 6A, 100 OHM 722888-0010
FB302 BEAD, FERRITE, 1806, 6A, 100 OHM 722888-0010
FB303 BEAD, FERRITE, 1806, 6A, 100 OHM 722888-0010
J200 CONN, BRD-BRD, MALE, T ENTRY, 20POS, GRY 357552-0020
J300 CONN, HEADER, 4POS, 1.25mm, MALE, WHITE 330701-0004
Reference
Designator
Description Material Number Note
U300 IC, PWR AMP, CLASS D, 2X30W, 8 OHM, 32SO 356443-0010
3
؍
ELECTRICAL PART LIST
Amp PCB Part List
Capacitors (Continued)
