19
Reference
Designator
Description Material Number Note
R702 RES, 0402, 47.5K, 1/16W, 1% 268361-4752
R703 RES, 0402, 63MW, 1%, 100K 268361-1003
R708 RES, 0402, 63MW, 1%, 100K 268361-1003
R713 RES, 0402, 63MW, 1%, 100K 268361-1003
R714 RES, 0402, 63MW, 1%, 100K 268361-1003
R715 RES, 0402, 63MW, 1%, 20.5K 268361-2052
R716 RES, 0402, 63MW, 1%, 20.5K 268361-2052
R717 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R718 RES, 0402, 63MW, 1%, 23.7K 268361-2372
R719 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R720 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R721 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R722 RES, 0402, 63MW, 1%, 100K 268361-1003
R723 RES, 0402, 63MW, 1%, 23.7K 268361-2372
R901 RES, 0805, 1/8W, 1%, 3.01K 173767-3011
R902 RES, 0805, 1/8W, 1%, 3.01K 173767-3011
R903 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R904 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
Reference
Designator
Description Material Number Note
C601 CAP, 0805, COG, 50V, 5%, 180pF 133622-181
C701 CAP, X7R, 0402, 16V, 5%, 0.1uF, COMM 718866-104J1C
C703 CAP, X7R, 0402, 16V, 5%, 0.1uF, COMM 718866-104J1C
C704 CAP, X7R, 0402, 16V, 5%, 0.1uF, COMM 718866-104J1C
C705 CAP, X7R, 0402, 16V, 5%, 0.1uF, COMM 718866-104J1C
C706 CAP, X7R, 0603, 1uF, 16V, 10% 257154-105K16
C709 CAP, X7R, 0603, 1uF, 16V, 10% 257154-105K16
C801 CAP, X7R, 0402, 16V, 5%, 0.1uF, COMM 718866-104J1C
C902 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
C903 CAP, COG, 0402, 5%, 180pF, 50V 268364-181
C904 CAP, X7R, 0402, 16V, 5%, 0.1uF, COMM 718866-104J1C
C905 CAP, X7R, 0402, 16V, 5%, 0.1uF, COMM 718866-104J1C
C906 CAP, 0805, COG, 50V, 5%, 180pF 133622-181
C909 CAP, X7R, 0402, 25V, 5%, 10nF 268367-103
C910 CAP, X7R,0603, 16V, 10%, 0.1uF 257154-104K16
C913 CAP, X7R, 0402, 16V, 10%, 1000pF 293702-102
Capacitors
ELECTRICAL PART LIST
I/O PCB Part List
Resistors
