Bose SoundLink Mini - Operation; Battery Power and Management

20
Reference
Designator
Description Material Number Note
D702 DIODE, SOT-23, BAV99 147239
D703 DIODE, SOT-23, BAV99 147239
D704 DIODE, SCHTKY, SC70, 30V, COM. CATH 268381-003
ZR701 DIODE, ZEN, 5.6V, 225MW, 5%, SOT-23 135247-5232
Transistors
Reference
Designator
Description Material Number Note
Q701 XSISTOR, BIAS, PNP, 0.03A, 50V, 47K/47K, SOT23 351912-0010
Q702 TRANSISTOR, MOSFET, P-CH, 4A, 20V, SOT-23 626239-0010
Q703 TRANSISTOR, MOSFET, P-CH, 4A, 20V, SOT-23 626239-0010
Q704 XSISTOR, BIAS, PNP, 0.03A, 50V, 47K/47K, SOT23 351912-0010
Q705 TRANSISTOR, MOSFET, P-CH, 4A, 20V, SOT-23 626239-0010
Q706 TRANSISTOR, MOSFET, P-CH, 4A, 20V, SOT-23 626239-0010
Q707 XSISTOR, BPLR, P, 40V, 200mA, SOT23 148596
Q708 BSS ASSY, SOUNDLINK MINI BT 2, IO 716542-0010
Integrated Circuits
Reference
Designator
Description Material Number Note
U701 IC, VOLTAGE COMPARATOR, LM339 187618-001
U901 MICROPHONE, MEMS, BOTTOM PORT, AKU440 728418-0010
Miscellaneous
Reference
Designator
Description Material Number Note
FB901 JUMPER, CHIP, 0603 196042
J901 CONN, CUSTOM, IO, 3.5MM, MICRO USB-B NG6 726796-0010
J903 CONN, FFC, 0.5mm, S ENTRY, 34POS 363842-34S2
J905 CONN, CUSTOM, BATTERY, 4POS, BLK 360718-0010
S801 IC, MUX/DEMUX, 2X2:1, USB, TS3USB221E, 10QFN 353620-0030
ELECTRICAL PART LIST
I/O PCB Part List
Diodes
