Bose SoundLink Mini

9
Reference
Designator
Description Material Number Note
R204
RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R205 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R209 RES, 0402, 63MW, 1%, 4.99K 268361-4991
R211 RES, 0402, 0.063W, 1%, 30.1 OHMS 268361-30R1
R212 RES, 0402, 0.063W, 1%, 30.1 OHMS 268361-30R1
R213 RES, 0402, 0.063W, 1%, 30.1 OHMS 268361-30R1
R214 RES, 0402, 0.063W, 1%, 30.1 OHMS 268361-30R1
R215 JUMPER, 0402, 0 OHM 280043
R216 JUMPER, 0402, 0 OHM 280043
R217 JUMPER, 0402, 0 OHM 280043
R218 JUMPER, 0402, 0 OHM 280043
R219 JUMPER, 0402, 0 OHM 280043
R220 JUMPER, 0402, 0 OHM 280043
R221 RES, 0402, 63MW, 1%, 4.99K 268361-4991
R223 RES, 0402, 63MW, 1%, 4.99K 268361-4991
R224 JUMPER, 0402, 0 OHM 280043
R225 JUMPER, 0402, 0 OHM 280043
R226 JUMPER, 0402, 0 OHM 280043
R301 RES, 0402, 63MW, 1%, 1K 268361-1001
R303 JUMPER, 0402, 0 OHM 280043
R304 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R305 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R306 RES, 0402, 63MW, 1%, 4.99K 268361-4991
R307 RES, 0402, 63MW, 1%, 4.99K 268361-4991
R401 RES, 0805, .125W, 1%, 3.48K 133625-3481
R402 RES, 0805, .125W, 1%, 3.48K 133625-3481
R403 RES, 0402, 63MW, 1%, 249 OHM 268361-2490
R404 RES, 0402, 63MW, 1%, 249 OHM 268361-2490
R405 RES, 0402, 63MW, 1%, 249 OHM 268361-2490
R406 RES, 0402, 63MW, 1%, 249 OHM 268361-2490
R409 RES, 0402, 63MW, 1%, 1K 268361-1001
R410 RES, 0805, .125W, 1%, 475 133625-4750
R411 RES, 0805, .125W, 1%, 475 133625-4750
R412 RES, 0402, 63MW, 1%, 3.74 KOHM 268361-3741
R413 RES, 0402, 63MW, 1%, 3.74 KOHM 268361-3741
R414 RES, 0402, 63MW, 1%, 3.74 KOHM 268361-3741
R415 RES, 0402, 63MW, 1%, 3.74 KOHM 268361-3741
R416 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R417 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R503 RES, 0402, 0.063W, 1%, 46.4K 268361-4642
R504 RES, 0402, 63MW, 1%, 200 OHM 268361-200R
R505 RES, 0402, 0.063W, 1%, 46.4K 268361-4642
Main PCB
Resistors
ELECTRICAL PARTS LIST
