Bose SoundTouch 30 Series III User Manual

10
ELECTRICAL PART LIST
SoundTouch™ Common Module PCB Assembly
Resistors
Reference
Designator
Description Part Number Note
R202 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R203 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R204 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R205 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R207 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R208 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R209 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R210 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R211 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R212 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R213 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R214 RES, 0402, 63MW, 1%, 49.9 OHM 268361-49R9
R215 RES, 0402, 63MW, 1%, 49.9 OHM 268361-49R9
R216 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R218 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R219 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R220 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R222 RES, 0402, 63MW, 1%, 49.9 OHM 268361-49R9
R223 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R224 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R225 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R226 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R301 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R302 RES, 0402, 0.063W, 1%, 4.53kOHMS 268361-4531
R303 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R304 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R306 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R307 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R310 RES, 0402, 63MW, 1%, 56.2K 268361-5622
R311 RES, 0402, 63MW, 1%, 56.2K 268361-5622
R312 RES, 0402, 63MW, 1%, 56.2K 268361-5622
R313 RES, 0402, 63MW, 1%, 56.2K 268361-5622
R314 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R315 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R316 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R318 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R319 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R320 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R321 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R322 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R323 RES, 0402, 63MW, 1%, 90.9K 268361-9092
R404 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R405 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R406 RES, 0402, 0.063W, 1%, 4.7OHMS 268361-4R70
R407 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R408 RES, 0402, 63MW, 1%, 301 OHM 268361-3010
R409 RES, 0402, 63MW, 1%, 301 OHM 268361-3010
R410 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R411 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R412 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R413 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R414 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R501 RES, 0402, 63MW, 1%, 1.0M 268361-1004
R502 RES, 0402, 63MW, 1%, 1.0M 268361-1004
R503 RES, 0402, 63MW, 1%, 1.0M 268361-1004
R504 RES, 0402, 63MW, 1%, 3.32K OHM 268361-3321
R505 RES, 0402, 63MW, 1%, 3.32K OHM 268361-3321
R506 RES, 0402, 63MW, 1%, 3.32K OHM 268361-3321
R507 RES, 0402, 63MW, 1%, 3.32K OHM 268361-3321
R508 RES, 0402, 0.063W, 1%, 4.7OHMS 268361-4R70
R509 RES, 0402, 63MW, 1%, 100K 268361-1003
R510 RES, 0402, 63MW, 1%, 100K 268361-1003
R511 RES, 0402, 63MW, 1%, 100K 268361-1003
R512 RES, 0402, 63MW, 1%, 100K 268361-1003
R513 RES, 0402, 0.063W, 1%, 4.7OHMS 268361-4R70
R514 RES, 0402, 63MW, 1%, 49.9 OHM 268361-49R9
R515 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R601 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R602 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R603 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R604 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R605 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R606 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R607 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R608 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R609 RES, 0402, 63MW, 1%, 1.50K 268361-1501
Reference
Designator
Description Part Number Note
R610 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R611 RES, 0402, 0.063W, 1%, 4.53kOHMS 268361-4531
R612 RES, 0402, 0.063W, 1%, 4.53kOHMS 268361-4531
R613 RES, 0402, 0.063W, 1%, 4.53kOHMS 268361-4531
R614 RES, 0402, 0.063W, 1%, 4.53kOHMS 268361-4531
R615 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R617 RES, 0402, 63MW, 1%, 12.1K 268361-1212
R618 RES, 0805, .125W, 1%, 52.3 133625-52R3
R619 RES, 0805, .125W, 1%, 52.3 133625-52R3
R620 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R621 RES, 0805, .125W, 1%, 52.3 133625-52R3
R622 RES, 0805, .125W, 1%, 52.3 133625-52R3
R623 RES, 0805, .125W, 1%, 274 133625-2740
R624 RES, 0805, .125W, 1%, 274 133625-2740
R901 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R902 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R903 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R904 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R905 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R906 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R907 RES, 0402, 63MW, 1%, 44.2K 268361-4422
R908 RES, 0402, 0.063W, 1%, 4.53kOHMS 268361-4531
R909 RES, 0402, 63MW, 1%, 56.2K 268361-5622
R910 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R911 RES, 0402, 63MW, 1%, 10.0K 268361-1002
R912 RES, 0402, 63MW, 1%, 12.1K 268361-1212
R913 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R914 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R915 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R1001 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R1002 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R1003 RES, 1206, 1/4W, 5%, 10 OHM 124895-1005
R1005 RES, 1206, 1/4W, 5%, 4.7 OHM 124895-4R75
R1006 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R1007 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R1009 RES, 0402, 63MW, 1%, 44.2K 268361-4422
R1201 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R1202 RES, 0402, 63MW, 1%, 100K 268361-1003
R1203 RES, 0402, 63MW, 1%, 100 OHM 268361-1000
R1204 RES, 0402, 63MW, 1%, 499 OHM 268361-4990
R1205 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R1602 RES, 0402, 63MW, 1%, 100K 268361-1003
R1603 RES, 0402, 0.063W, 1%, 7.87kOHMS 268361-7871
R1701 RES, 0402, 63MW, 1%, 1.50K 268361-1501
R1702 RES, 0402, 63MW, 1%, 221K 268361-2213
R1703 RES, 0402, 63MW, 1%, 44.2K 268361-4422
Resistors

Bose SoundTouch 30 Series III Specifications

General

Included Remote	Yes
Connectivity	Wi-Fi, Bluetooth, Ethernet
Audio formats supported	MP3, WMA, AAC, Apple Lossless
Inputs	3.5mm auxiliary input
Power Source	Internal
Compatibility	Amazon Alexa
Audio Output	Stereo
