Bose SoundTouch 30 Series III User Manual

8
SPEAKER ASSEMBLY PART LIST
Bose
®
SoundTouch
®
30 WiFi Music System
See Page 9 for diagram
Item
Number
Description Part Number Note
1 COVER, REAR, SOUNDLINK
30, GRY
355068-0130 3,
COVER, REAR, SOUNDLINK
30, BLK
355068-0110
2 TAPE, FOAM, PORON,
70X20X3.05mm
369746-0010
3 TAPE, FOAM, 35X20X4.78mm 627255-0010
4 GASKET, FOAM, PORT 311943-0010
5 HARNESS, GROUND STRAP,
W/FOAM
374892-0020
6 PAD, RUBBER 374380-0010
7 CABLE ASSY, FFC,
STRAIGHT, 31POS
360505-0010 6
CABLE ASSY, FFC,
FOLDED, 31POS NEW
HIROSE CONNECTOR
749202-0010
8 CABLE, FFC, MOJO, 0.5mm, 1
FOLD, 42COND, 470mm
355057-0010
9 SCREW, TAP, 8-11X.625,
PAN, XRC/SQ
289389-010
10 COVER, WOOFER, E-COAT 310388-002
11 Gasket, Wave Guide 313891-004
12 TRANSDUCER
ASSEMBLY,116mm
324318-001S 3,
13 Gasket, Center Plug 316806-002
14 *SLAB ASSY, SOUNDTOUCH
II WI-FI BOARD (see page 29)
*720048-024S 4, 6
*SLAB ASSY, SOUNDTOUCH
II WI-FI BOARD NEW HIROSE
CONNECTOR (see page 29)
*720048-034S
15 SCREW, TAPP, 4-16X.38,
PAN, XREC
288372-006
16 TAPE, FOAM, PORON,
15X10X4.78mm
369747-0010
17 SCREW,SELF TAPPING,
M2.5X7mm, WASHER, TORX
357328-0070
18 PCB ASSY, SOUNDTOUCH
20/30, BTTN
359563-001S
19 KEYPAD ASSY, PULSE GRAY 354213-0030
KEYPAD ASSY, PULSE BLK 354213-0040
20 TAPE, FOAM, PORON,
1.25X423X10mm
360493-0060
21 SCREW, TAPP, 8-11x.5, PAN,
XREC/SQ
289388-008
22 TOP CAP, IMD, NO
HARDCOAT, WHT
355065-0040 3,
TOP CAP, IMD, NO
HARDCOAT, BLK
355065-0030
23 CABLE, FFC, MOJO, AD,
0.5mm, 12COND, 135mm
355056-0020
24 TAPE, POLYIMIDE,
2.5ML 0.001 Roll
137926
25 CABLE, FFC, MOJO, 0.5mm,
10COND, 90mm
355055-0010
26 ENDCAP, RIGHT, IMD, INK,NO
HARDCOAT, WHT
355064-0040 3,
ENDCAP, RIGHT, IMD, INK,NO
HARDCOAT, BLK
355064-0030
*The replacement Wi-Fi PCB needs to have various settings performed
and end user software loaded. See page 29 for details
Item
Number
Description Part Number Note
27 TAPE, FOAM, PORON, SLIDE 357318-0020
28 TWIDDLER, 50mm 359302-0010 3,
29 FOAM, ACOUSTIC 313881-001
30 GRILLE ASSY, GRY 357322-0040 3,
GRILLE ASSY, BLK 357322-0010
31 DISPLAY (includes lens and
display board)
625094-001S 5
32 LENS, SOUNDTOUCH 30 357185-0010
33 FOAM, GRILLE, ARRAY 272036-001
34 CLIP, GRILLE 359456-0010
35 HARNESS, TWIDDLER 318606-0020
36 TAPE, FOAM, CENTER 360493-0010
37 GASKET, SHIELDING,
BLACK
347824-0010
38 BRACKET, BOTTOM 354742-0010 3,
39 PCB, SOUNDTOUCH 30 ,
PWR SPLY, 120V, US
354778-001S 3,
PCB, SOUNDTOUCH 30 ,
PWR SPLY, 240V, EU
354778-002S
40 PCB ASSY, SOUNDTOUCH
30 , I/O,
354979-001S 3, 6
PCB ASSY, SOUNDTOUCH
30 , I/O, NEW HIROSE
CONNECTOR
354979-011S
41 GASKET, EMI, FOAM,
40X30X5mm
323770-0020 3,
42 FOOT, RUBBER,12.5 DIA 627991-0010 3,
43 LABEL, VOLTAGE WARNING 359403-0010
44 BASEPLATE, SOUNDLINK
WIFI,A-COAT
355066-0010 3,
45 CABLE, FFC, DSP, SHLD,
30COND, 99.5mm
311560-0050
46 HARNESS,AC POWER, 300V,
2COND, 140mm
330634-0030
47 PAD, THERMAL 311554-0010
48 HEATSINK, MOJO, PWR
SUPPLY
357258-0010 3,
49 WELDED ASSY, LC-WG-TB-
TC
627487-001S 3,
50 TAPE, FOAM, 70X10X2.36mm 627256-0010
51 ENDCAP, LEFT, IMD, INK, NO
HARDCOAT, WHT
355062-0040 3,
ENDCAP, LEFT, IMD, INK, NO
HARDCOAT, BLK
355062-0010
52 HARNESS, WOOFER, 355062-0030

Bose SoundTouch 30 Series III Specifications

General

Included Remote	Yes
Connectivity	Wi-Fi, Bluetooth, Ethernet
Audio formats supported	MP3, WMA, AAC, Apple Lossless
Inputs	3.5mm auxiliary input
Power Source	Internal
Compatibility	Amazon Alexa
Audio Output	Stereo
