Boss AC-3 - Connecting to Guitar Amp and PA System Simultaneously

11
Connections
When Connecting Both to a Guitar Amp and PA System (or Recorder
or Similar Equipment)
■ With Effect On
The CHECK indicator lights, the output from the AC-3: G.AMP OUT jack is muted, and the
effect sound is output from the LINE OUT jack.
fig.11
PA System
Recorder
Guitar Amp Multiple Effects, etc.
Effect sound
Mute
AC Adaptor
BOSS PSA-series
(sold separately)
Electric Guitar
