Boss AD-5 - Panel Descriptions

6
Panel Descriptions
EFFECTS BYPASS (page 12)
ACOUSTIC (page 10)
PREAMP
(page 9)
REVERB (page 11)
2x2 CHORUS (page 11)
OUTPUT Jacks (L,R) (Balanced) (page 7)
POWER Indicator
(page 8)
ANTI-FEEDBACK
(page 10)
PEAK Indicator
(page 8)
INPUT LEVEL
(page 8,9)
INSERT Jack (page 12)
INPUT Jacks (PIEZO,MAGNETIC) (page 7)
REMOTE Jack (page 13)
AC Adaptor Jack (page 7)
BALANCED OUTPUT Switch (page 7)
POWER Switch (page 8)
OUTPUT Jacks (L(MONO),R) (1/4 inch phone) (page 7)
