Boss CEB-3 User Manual

4
Panel Description
fig.01
1. AC Adaptor Jack
Accepts connection of an AC Adaptor (op-
tionally available BOSS PSA-Series). By
using an AC Adaptor, you can play with-
out being concerned about how much bat-
tery power you have left.
* Use only the specified AC adaptor (PSA-
Series), and make sure the line voltage at the
installation matches the input voltage
specified on the AC adaptor's body. Other
AC adaptors may use a different polarity, or
be designed for a different voltage, so their
use could result in damage, malfunction, or
electric shock.
* As soon as you connect the AC adaptor, the
unit is turned on.
* If there is battery in the unit while an AC
adaptor is being used, normal operation will
continue should the line voltage be interrupted
(power blackout or power cord disconnection).
3
1
6
4
5
2

Boss CEB-3 Specifications

General

Effect Type	Bass Chorus
Input Impedance	1 M ohm
Output Impedance	1 k ohm
Bypass	Buffered Bypass
Recommended Load Impedance	10 k ohm or greater
Controls	Rate, Depth, Low Filter
Connectors	INPUT jack, OUTPUT jack, AC Adaptor jack
Power Supply	DC 9V
Dimensions	73 (W) x 129 (D) x 59 (H) mm
Accessories	Owner's Manual, Dry Battery 9V type (6F22/9V)
