18
Attaching the Included Sticker
This device comes with a “mode sticker” and an “application sticker.”
Apply these to the DD-7 as shown in the gure.
Mode Sticker: This allows you to check the function of each mode.
Application Sticker: This allows you to check the dierence in functions according to the input and output connections.
Application Sticker Mode
Sticker
