Boss MS-3 Application Guide

11
MS-3 Example Settings (Functions)
Switching the Memory of a MIDI-Compatible Pedal When You Switch Patches
For each patch, you can specify which memory of the MIDI-compatible pedal is selected.
Example
Outputting PC#1 (program number 1) when patch 01-1 is recalled
1. Choose a patch 01-1.
2. Press the [EDIT] button. In the eect chain screen, choose “CTL” with the [1] knob, and press the [ENTER] button.
3. Choose “PATCH MIDI1”–“PATCH MIDI4” with the [1]–[3] knobs, and press the [ENTER] button.
4. Use the [1] knob to set the MIDI CH.
* Set this to match the MIDI channel of the MIDI-compatible pedal that's connected.
5. Press the [PAGE >] button to switch the PAGE 2.
6. Use the [3] knob to set PC to “1.”
7. Press the [EXIT] button and [ENTER] button simultaneously, then execute the Write operation.
* If you switch patches without performing the Write operation, your edits are discarded.
MEMO
If you want a CC (control change) to be transmitted simultaneously with the PC (program change), you can use PAGE 3 and PAGE 4 to specify
two dierent CC messages. For details, please refer to “Parameter Guide” (PDF).
Using an Externally Connected Expression Pedal to Operate a Parameter of a MIDI-Compatible Pedal
Here we explain how to use an expression pedal connected to the CTL IN EXP1 CTL 1/2 jack to control a CC (control change) in real time.
Example
Using EXP1 to control CC#1 (controller number 1) in real time
1. Press the [EDIT] button. In the eect chain screen, choose “CTL” with the [1] knob, and press the [ENTER] button.
2. Choose “ASSIGN 1”–“ASSIGN 8” with the [1]–[3] knobs, and press the [ENTER] button.
3. Use the [1] knob to set ASSIGN to “ON.”
4. Use the [2] knob to set SOURCE to “EXP1.”
5. Use the [3] knob to set MODE to “MOMENT.”
6. Press the [PAGE >] button to switch the PAGE 2.
7. Use the [1] knob to set CATEGORY to “MIDI.”
8. Use the [2] knob to set the same channel as the connected MIDI-compatible pedal.
9. Use the [3] knob to set CC# to “001.”
10. Press the [PAGE >] button to switch the PAGE 3.
11. Use the [1] knob to set MIN to “0.”
12. Use the [3] knob to set MAX to “127.”
13. Press the [PAGE >] button to switch the PAGE 4.
14. Use the [1] knob to set ACT.LOW to “0.”
15. Use the [3] knob to set ACT.HIGH to “127.”
16. Press the [EXIT] button and [ENTER] button simultaneously, then execute the Write operation.
* If you switch patches without performing the Write operation, your edits are discarded.
When the above settings are complete, operating an expression pedal connected to the CTL IN EXP 1 CTL 1/2 jack transmits CC#001 with a CC
VALUE of 0–127. For details, please refer to “Parameter Guide” (PDF).

Boss MS-3 Specifications

General

Bit rate	24 bit
Product color	Black
Sound effects	Delay, Looper
Sound effects quantity	112
AC adapter included	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
6.35 mm (1⁄4-inch) output	1
Display type	LCD
Power source type	DC

Weight and Dimensions

Depth	97 mm
Width	275 mm
Height	68 mm
Weight	1100 g
