7
MS-3 Example Settings (Functions)
Example 2
In manual mode, pressing number switch [1] to turn L1 and L2 on/o
* In order to operate multiple parameters simultaneously, the “PREFERENCE” (MENU) setting NUM1 must be set to “PATCH.” If this is set to
“SYSTEM,” only the setting of the single item listed below will operate.
1. In steps 1–4 of example 1 (p. 6), set FUNC to “L1” and MODE to “TOGGLE.”
If you want to switch both L1 and L2 on/o simultaneously
Perform the subsequent operations with L1 and L2 turned OFF.
If you want to switch L1 and L2 alternately on/o
Perform the subsequent operations with L1 turned OFF.
2. Press the [EXIT] button to return to the previous screen.
3. Choose “ASSIGN 1”– “ASSIGN 8” with the [1]–[3] knobs, and press the [ENTER] button.
4. Use the [1] knob to set ASSIGN to “ON.”
5. Use the [2] knob to set SOURCE to “NUM1.”
6. Use the [3] knob to set MODE to “TOGGLE.”
7. Press the [PAGE >] button to switch the PAGE 2.
8. Use the [1] knob to set CATEGORY to “L2.”
9. Use the [3] knob to set TARGET to “ON/OFF.”
10. Press the [PAGE >] button to switch the PAGE 3.
11. Use the [1] knob to set MIN to “OFF.”
12. Use the [3] knob to set MAX to “ON.”
13. Press the [PAGE >] button to switch the PAGE 4.
14. Use the [1] knob to set ACT.LOW to “0.”
15. Use the [3] knob to set ACT.HIGH to “127.”
16. Press the [EXIT] button and [ENTER] button simultaneously, then execute the Write operation.
* If you switch patches without performing the Write operation, your edits are discarded.
Step: On Step: O
MEMO
The MS-3 lets you assign a wide variety of parameters. For details, please refer to “Parameter Guide” (PDF).
