Boss MX1-3HL - Component Identification Table

www.bssindustrial.co.uk
We reserve the right to change designs and technical specifications of our products.
Rev 2.1 Oct-15 Page 22 / 28
#
Description
Part Code
1
Mini Float Valve
BSS M003
2
22 mm Overflow Connection
BSS M021
3
¼” Brass Nut
BSS M006
4
¼” Ball Valve
BSS M005
5
40 mm Pressure Gauge c/w Capillary
BSS M004
6
Rocker switch
BSS F014
7
6 mm Poly-tube
BSS M014
8
8 mm Poly-tube
BSS M015
9
Pump Control Pressure Switch
FC TBV BOSS
10
High/Low Pressure Switch
FC TBV TWIN
11
Fused Terminal Block
BSS R002
12
Pump – All Models (Model E EP77)
BSS M024
13
Flexible Pump Support Bracket
BSS M022
14
6mm x 8mm Push-Fit Manifold
FC MANIFOLD 8X6
