7. 3 Read from the CF card
• Enter the setting mode, choose 1. CF CARD and press RECORD , LCD will show
you:
1. READ FROM CF
2. STORE TO CF
• Use UP/DOWN buttons to choose 1. READ FROM CF , and press the RECORD
button to enter.
• Select relevant location (1-99) by UP/DOWN buttons, and press the RECORD button
for data reading, use ESC to cancel or exit.
7. 4 Patch channel (assign)
• Enter the setting mode to choose 2. ASSIGN CH. , and press RECORD to enter
channel distributing mode. LCD shows:
CHANNEL1 > OUT1
OK ESC SEL ADJ
• select
the fixtures to be distributed.
• Use
UP button to select relevant channel number, and press DOWN to select the
channel number to be distributed.
• Press RECORD button to confirm, and press ESC button to cancel or exit.
7. 5 PAN / TILT FADE ONLY
• Enter the setting mode to choose item 3. P/T FADE ONLY , and press the RECORD
button to enter “PAN/TILT FADE ONLY” mode.
Further information will be shown on the LCD:
FIXTURE1: ONLY
OK ESC SEL ADJ
• Select
fixtures by the UP button, and press the DOWN button to select “FADE ONLY”
or ”FADE ALL”.
• Press “RECORD” to confirm your operation, and “ESC” to cancel or exit.
7. 6 Display mode (100/255)
• Enter the setting mode and choose item 4. DISPLAY MODE , then press the
RECORD button to enter.
LCD will show you:
DISPLAY MODE : ×××
