4
4 Features and Specifications
4.1 Features
• Hybrid console for 16 DMX units (8 intelligent fixtures & 8 PARs)
• 6 freely programmable PAR programs, ONE/MIX/SEQ available
• 8 freely programmable fixture programs, MIX/SEQUENCE available
• 136 DMX channels(8 channels for PARs and up to 16 channels per fixture)
• 96 freely programmable fixture scenes / PAR scenes
• Speed, Fade Time and Master control for chases
• Joystick for Pan
/ Tilt & Pan fine / Tilt fine movement of fixture
• Free access of CF card(32M) for the exchange of data and memories
• Blackout overall output
• Fade time/Non-fade time under control
• Power failure memory and Fog Machine trigger
• MIDI control over scenes, chases and blackout
• Audio input and built-in microphone for music sync. function
4.2 Specifications
• Model DC-136
• Power Input
DC 9~15V, 600 mA min.
• LCD
2×16 characters
• Audio Trigger
Built-in microphone or line in
• DMX Output
3 PIN female DMX connector
• Dimensions
482×178×80mm
• Weight
Approx. 6.2 kg
5 Basic Control Parts
5.1 Front view
• SCENE buttons:
Press the scene buttons to load or store relevant Scenes.
• CHASE buttons:
These buttons are used to load or store relevant Chases.
• FIXTURE buttons:
To select fixtures for setting, programming or recording.
• Dimmer faders:
To control and adjust relevant dimming level for each channel.
