Botron ELITE - Mounting the Foot Plate

The ELITE footplate comes with 4 pre-drilled holes on the underside to securely
mount the test stand pole to the footplate.
Step 1. Lay the test stand pole on its back with the footplate mounting bracket
pointing upwards.
Step 2. Mount the footplate to the test stand pole using 4 screws into the
underside of the footplate.
MOUNT
YOUR
FOOT
PLATE
