The BougeRV fridge/freezer is equipped with a battery preservation monitor.It
hasthree settings to monitor your battery to prevent a full discharge. The higher
the setting the higher the cut-off voltage will be.
When set to HIGH, the battery monitor will provide maximum protection for the
battery running the fridge/freezer against excessive/full discharge.
When set to LOW, the battery monitor will allow the fridge/freezer to use more of
the battery energy.
Recommended temperature for common food:
The battery monitor will shut off the fridge/freezer as soon as the supply voltage
falls below the set level. The fridge/freezer will restart after 2 minutes once the
cut-in voltage is reached.
6.Car Battery Protection Voltage Reference
Voltage
NOTE:
Factory default voltage protection level sets to H Mode
Cut-out is the input voltage in which the fridge/freezer will turn off.
Cut-in is the input voltage in which the fridge/freezer will turn on.
High mode
12V DC
Cut out 11.3V 10.1V 9.6V
12.5V 11.4V 10.9V
24.6V 22.3V 21.3V
26.0V 23.7V 22.7V
Cut in
Cut out
Cut in
24V DC
Medium Mode Low mode
