Bowers & Wilkins 702 S3 User Manual

7
ENGLISH
Home Theatre Systems
If the speakers are to be used for the front channels in a home
theatre system, they should be placed closer together than for
2-channel audio, because the surround channels tend to widen
the image. Positioning the speakers within approximately 0.5m
of the sides of the screen will also help keep the sound image
in scale with the visual image. As with conventional stereo
positioning, the speakers should ideally be at least 0.5m away
from any side walls.
Stray Magnetic Fields
The speaker drive units create stray magnetic elds that extend
beyond the boundaries of the cabinet. We recommend you keep
magnetically sensitive articles (CRT television and computer
screens, computer discs, audio and video tapes, swipe cards and
the like) at least 0.5m from the speaker. LCD, OLED and plasma
screens are not affected by magnetic elds.
>0.5m
110° - 130°
~40°
5 Channels 7 Channels
0.5m - 1m 0.5m - 1m

Bowers & Wilkins 702 S3 Specifications

General

Type	Floorstanding speaker
Midrange	1x 150mm (6 in) Continuum cone FST midrange
Sensitivity	90dB spl (2.83Vrms, 1m)
Impedance	8Ω (minimum 3.1Ω)
Net Weight	29.5 kg (65 lbs)
Tweeter	1x 25mm (1 in) Decoupled Carbon Dome
Frequency Range	28Hz to 33kHz
Frequency Response	46Hz - 28kHz ±3dB
Recommended Amplifier Power	30W - 300W
Dimensions	200mm (7.9 in) width
Finish	Gloss Black, Satin White
Bass	3x Ø165mm (6.5 in) Aerofoil Profile bass
