137
5. Using a #2 Phillips screwdriver, remove the two indicated screws from
the Rear Roller Cover.
6. Remove the Rear Roller Cover noting how it attaches for re-assembly.
7. Using a #2 Phillips screwdriver, remove the 4 indicated screws that
secure the Side Rail. Remove it from the machine.
Rear Roller Cover
Side Rail
