Bowflex BXT116 - Page 168

168
20.Usinga6mmhexwrench,removetheindicatedAdjustmentBolts
(with arrows) from the Rear Roller.
Note: Be sure to record the number of turns of the Adjustment Bolt it
takes to remove it. This will assist with reassembly.
21. Slide the Rear Roller out of the Walking Belt.
22.Usinga6mmhexwrench,removethe3indicatedscrewsfromthe
Walking Deck.
Walking Deck
Rear Roller
