178
20.Usinga6mmhexwrench,removethe3indicatedscrewsfromeach
side of the Walking Deck.
21.SlidetheoldWalkingDeckAssemblyoutoftheWalkingBelt,andip
oversotheWalkingBeltGuidesareexposed.
Note: the Walking Deck is designed for wear on both sides of it. If this is
thersttimeremovingtheWalkingDeck,areplacementDeckmaynot
be required. Flip the Walking Deck and use the unworn side as the “new
Walking Deck”.
22. Using a #2 Phillips screwdriver, remove the Walking Belt Guides and
attach them to the new Walking Deck in the same orientation.
23. Turn over the new Walking Deck Assembly, and replace it between the
Walking Belt in the same orientation.
24.Usinga6mmhexwrench,re-installthe6screwstotheDeck.
25. Re-install all remaining parts that were removed in reverse order.
Note: Make sure the treadmill is located on a surface that is easy to
Walking Deck
Walking Belt
Guides
clean.
26. Apply a few drops of the lubricant on the deck below the belt. Carefully lift the belt and apply a few drops of the lubricant the entire width of the
belt. A very thin layer of silicone lubricant on the entire deck below the belt is desired.
NOTICE: Always use a 100% pure silicone lubricant. Do not use a degreaser like WD-40
®
as this could seriously impact performance. We can
recommend that you use the following:
• 100% pure silicone, available at most hardware and auto parts stores.
• Lube-N-Walk
®
TreadmillLubricationKit,availablefromyourlocalspecialtytnessdealerorNautilus,Inc.
Silicone lubricant is not intended for human consumption. Keep out of reach of children. Store in a safe place.
27. Manually rotate the belt 1/2 of the length of the belt and apply lubricant again.
If you used spray lubricant, wait 5 minutes before turning on power to the machine to allow the aerosol to dissipate.
28. Connect the power cord back into the machine and then into the wall outlet.
