64
5. Using a #2 Phillips screwdriver, remove the two indicated screws from
the Rear Roller Cover.
6. Remove the Rear Roller Cover noting how it attaches for re-assembly.
7. Using a #2 Phillips screwdriver, remove the 5 indicated screws from the
Deck Suspension Inserts.
8. Remove the old Deck Suspension Inserts and attach the new Inserts.
9. Re-install all parts that were removed in reverse order.
10.Makesurethereissufcientspacetolowerthewalkingdeck.
Keep a minimum clearance behind the machine of 79” (2 m)
and 24” (0.6 m) on each side. This is the recommended safe
distance for access, movement and emergency dismounts
from the machine.
11. Make sure there is no object on or around the treadmill to spill or
cause blockage from the fully unfolded position.
Rear Roller Cover
